Our EC105 comes complete with a NSF certified 3.2
gallons water storage tank, USA made membrane and
all the necessary fittings, installation kits,
extra color 1/4" tubing, and a long-reach chrome
faucet.
Features:
3.2 Gallons NSF Standards Water Storage Tank.
FDA Approved Polypropylene Made Flat Cap Housing
(double o'ring).
Automatic Shut-off Valve, Mini Flow Restrictor,
Stainless Steel Check Valve.
Long Reach Chrome Faucet (upgrade faucet is
acceptable)
Feed water connector.
Drain Saddle Valve.
Four Color Coded 1/4 inch Tubing for System
Connection
Completely Assembled
100% Factory Tested and Sterilized Ready for
Installation.
Installation Instruction.
EC105 CARTRIDGE FILTERS
(Stage 1) 5 Micron Sediment Filter :
With only five micron rating. It is effective in
removing dirt, rust and sand particles.
(Stage 2) Granular Activated Carbon Filter:
It takes out 99% of the chlorine and organic
chemicals. It provides enhanced reduction of
taste, odor, and color.
(Stage 3) 1 Micron Sediment Filter :
With only 1 micron rating, provides effective
filtration to protect your membrane. It provides
for improved membrane performance up to 95% of TDS
rejection.
(Stage 4) Reverse Osmosis Membrane:
A thin film composite (TFC) high quality membrane
that processes 50 gallons per day. It remove the
following hard water contaminants that may be
present in your water: lead, cooper, barium,
chromium, mercury, sodium, cadmium, fluoride,
nitrite, nitrate, and selenium.
(Stage 5) Post Carbon filter:
This carbon post filter removes objectionable
tastes and odors to enhance the quality of your
drinking water. We are using NSF approved post
carbon to guarantee the taste of water.
--------------------------------------------------------------------------------
Specifications:
Membrane: 50 GPD / 189 LPD
Operation pressure: 50 -100 psi
Dimensions: (cm) 37 (L) x 45(H) x 20 (W) - system
(cm) 28 (L) x 28(W) x 35 (H)- tank
Weight: 8 kg - system
4 kg - tank
